Non Woven Polyester Combination Mat for Geogrid

Non Woven Polyester Combination Mat for Geogrid


Basic Info.

Model NO.
GT Non-woven polyester composite mat
Material
Polyester +Fiberglass
Type
Composite Geotextile
Roll Length
1200m or 1300m
Width
1 Meter
Transport Package
Carton or Pallet
Specification
90g/m2, 100g/m2, 110g/m2, 120g/m2
Trademark
GT
Origin
China
Production Capacity
500000 Square Meter Per Month


E-mail:guotai@fiberglass-china.com


CONTACT US

Product Description

Non-woven polyester composite mat



Introduction:
Fiberglass combination non-woven is made on the base of non woven by compositing some density glass fiber,through high temperauture, stoving, finalizing the design. It is a kind of reinforecement combination material. Application: It is used for making modified SBS waterproof material, and for waterproof in the underground,building roofing,ground and pond.


Features:

  • High-density glass fiber composite
  • Excellent reinforcement material
  • Perfect for making modified SBS waterproof material
  • Great for waterproofing in underground areas, building roofing, ground, and ponds


Technical data:
Mesh size
Length(m)
Width
(m)
Gram Weight
(g/m2)
Diameter
(mm)
Tensile strength (Weft/warp)N
Elongation
(%)
Temp.resistance
(°C)
Shrinkrage
(%)
3x3
1300
1
90
<=780
280/230
<5
<210
1
4x4
1300
1
100
<=780
350/300
<5
<210
1
5x5
1200
1
110
<=780
450/400
<5
<210
1
6x6
1200
1
120
<=780
550/500
<5
<210
1
